Great Com-192(M)

Great Com-192(M) Smart Mobile Energy Storage Charging Vehicle

A small smart mobile energy storage and charging vehicle with autonomous driving upgrade support.

Electrical & Mechanical SpecificationsPackaging & DeliveryCertifications

Submit project parameters. Great Power returns datasheet, pricing and lead time within 24 hours.

Vehicle Dimensions	L×D×H: 18001100550 mm
Total Weight	200 kg
Load Capacity	Rated 1800 kg, Max 2000 kg
Drive Mode	Rear wheel central motor drive, Ackermann chassis scheme
Min Ground Clearance	180 mm
Max Wading Depth	150 mm
Emergency Braking Distance	100 mm (at 5 km/h)
Drive Motor Power	≥3.6 kW
Model Number	C208-DC614L314V1
Display	7-inch full-color LCD screen
Battery Type	Lithium Iron Phosphate (LFP)
Battery Group Scheme	1P192S
Rated Capacity	314 Ah / 280 Ah
Rated Voltage	614 V
Working Voltage	537 V ~ 691 V
Rated Energy	172 kWh / 192 kWh
Cooling Method	Natural cooling
Protection Rating	IP65
Rated Charge Current	150 A
Rated Discharge Current	150 A
